Neodymium Pot Magnets, BNA Series, Countersunk

From $1.63$53.00

Clear

Neodymium Countersunk Rings and Countersunk Ring Magnets are made in a variety of sizes and grades to meet all types of applications. To accomplish a flush and smooth finish, use Neodymium Ring Magnets made with a single (or double) countersunk hole. Please note these countersunk ring magnets have the magnetic pole on the countersunk face stated. With today’s technology, there are so many ways to hold items together, but some methods are better than others. For example, the proper setting of magnets onto wood surfaces by screwing the magnets onto the frames is a proven method of success. A Neodymium Countersunk Ring offers a quick and simple installation resulting in optimum holding results. Applications for Countersunk Rings include closures, hanging items, and clamping situations. Neodymium Magnets are a composition of Neodymium, Iron and Boron blended, shaped and heat treated to result in a super-strong magnet. If left exposed to the elements, the iron in the magnet will rust. To protect the magnet from corrosion and to strengthen the brittle magnet material, it can be coated with corrosion-resistant nickel plating from .0004 inch to .0008 inch thick. We stock Neodymium Countersunk N42 Rings in a variety of sizes in for immediate shipment.

Weight N/A
Dimensions N/A
Size (D x T)

0.63 in x 0.25 in, 0.787 in x 0.283 in, 0.984 in x 0.303 in, 1.26 in x 0.307 in, 1.417 in x 0.3 in, 1.654 in x 0.346 in, 1.89 in x 0.425 in, 2.362 in x 0.59 in, 2.953 in x 0.7 in

Diameter

0.63 in, 0.787 in, 0.984 in, 1.26 in, 1.417 in, 1.654 in, 1.89 in, 2.362 in, 2.953 in

Inside Diameter

0.137 in, 0.177 in, 0.216 in, 0.256 in, 0.335 in, 0.413 in

Thickness

0.25 in, 0.283 in, 0.3 in, 0.303 in, 0.307 in, 0.346 in, 0.425 in, 0.59 in, 0.7 in

Screw Size

#10, #11, #12, #14, #4, #6, #8

Holding Force (lbs)

11, 13, 149.7, 246.6, 30.7, 356.7, 55, 63.8, 81.3

Material

Neodymium

Package Quantity

1

Specs

  • PART # BNA-20

    Size (D x T)0.787 in x 0.283 in
    Diameter0.787 in
    Inside Diameter0.177 in
    Thickness0.283 in
    Screw Size#6
    Holding Force (lbs)13
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD.787
    ID.177
    T.283
  • PART # BNA-32

    Size (D x T)1.26 in x 0.307 in
    Diameter1.26 in
    Inside Diameter0.216 in
    Thickness0.307 in
    Screw Size#8
    Holding Force (lbs)55
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD1.260
    ID.216
    T.307
  • PART # BNA-36

    Size (D x T)1.417 in x 0.3 in
    Diameter1.417 in
    Inside Diameter0.256 in
    Thickness0.3 in
    Screw Size#10
    Holding Force (lbs)63.8
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD1.417
    ID.256
    T.300
  • PART # BNA-25

    Size (D x T)0.984 in x 0.303 in
    Diameter0.984 in
    Inside Diameter0.216 in
    Thickness0.303 in
    Screw Size#8
    Holding Force (lbs)30.7
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD.984
    ID.216
    T.303
  • PART # BNA-16

    Size (D x T)0.63 in x 0.25 in
    Diameter0.63 in
    Inside Diameter0.137 in
    Thickness0.25 in
    Screw Size#4
    Holding Force (lbs)11
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD.630
    ID.137
    T.250
  • PART # BNA-75

    Size (D x T)2.953 in x 0.7 in
    Diameter2.953 in
    Inside Diameter0.413 in
    Thickness0.7 in
    Screw Size#14
    Holding Force (lbs)356.7
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD2.953
    ID.413
    T.700
  • PART # BNA-42

    Size (D x T)1.654 in x 0.346 in
    Diameter1.654 in
    Inside Diameter0.256 in
    Thickness0.346 in
    Screw Size#10
    Holding Force (lbs)81.3
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD1.654
    ID.256
    T.346
  • PART # BNA-60

    Size (D x T)2.362 in x 0.59 in
    Diameter2.362 in
    Inside Diameter0.335 in
    Thickness0.59 in
    Screw Size#12
    Holding Force (lbs)246.6
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD2.362
    ID.335
    T.590
  • PART # BNA-48

    Size (D x T)1.89 in x 0.425 in
    Diameter1.89 in
    Inside Diameter0.335 in
    Thickness0.425 in
    Screw Size#11
    Holding Force (lbs)149.7
    MaterialNeodymium
    Package Quantity1
    DiagramView Spec Image
    OD1.890
    ID.335
    T.425
